Categories
Ordering Code
MSV | 86 | 52 | 2 | R |
Specification Code | Series Code | Position and Way NO. | Port Size | Button Type |
Mechanical Valve | 86 Series | 32:3/2 Way | 1:G1/8'' | Blank:Basic Type |
98 Series | 52:5/2 Way | 2:G1/4'' | R:Roller Type | |
TB:Selective Knob | ||||
LB:Strengthened Knob | ||||
PB:Large Round Button | ||||
PP:Plat Round Button | ||||
PPL:Convex Round Button | ||||
EB:With Lock Button |
Specification Code
Model | MSV86321 | MSV86522 | MSV98322 |
Working Medium | 40 micron filtered air | ||
Position and Way No. | 3/2 way | 5/2 way | 3/2 way |
Effective Section Area | 12mm2(CV=0.67) | 16mm2(CV=0.89) | 16mm2(CV=0.89) |
Port Size | G1/8'' | G1/4'' | G1/4'' |
Working Pressure Range | 0~0.8MPa | ||
Operating Temperature Range | 0~60ºC |
